Havis-Shields K9/Prisoner Transportation System KK-K9-F14-K-PT - Manual

INSTALL INSTRUCTIONS KK-K9-F14-K-PT
K9/PRISONER TRANSPORTATION SYSTEM
2003-2009 FORD EXPEDITION
HARDWARE:
QTY: DESCRIPTION: PART
#:
28 ¼-20 x ½” Stainless carriage bolt GSM32022
8 ¼-20 x ¾” Stainless carriage bolt GSM32024
64 ¼-20 flanged serrated nut GSM30023
6 ¼-20 x ¾” Hex head cap screw GSM33001
6 ¼” x 1 ½” Hex head lag screw GSM33062
36 #12 x ¾” Stainless sheet metal screw GSM34177
24 #10 x ¾” Stainless sheet metal screw GSM34170
12 #10 x ½” Stainless sheet metal screw GSM34169
10 10-32 x ¾” Stainless machine screw GSM34098
6 #10 x ¾” Sheet metal screw GSM33195
1 Tube silver caulk PRM97343
1 46” x 45 ½” Rubber Floor mat KNM01029-SUV
10 #10 x ½” Flat head sheet metal screw GSM33150
1 ¼” Lexan shield/PT front partition KNM001220
Always
!
¾ Read all instructions before installing any Havis-Shields Equipment Corp products.
¾ Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
¾ Use hardware provided with install kit
¾ For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html , email [email protected] or call
1-800-524-9900.
