80 Using accessories Back to TOC
4 If you are scanning fewer than three slides, insert the slide light
shield after you load your last slide.
5 Place the XPA light source into the positioning plate with slides
facing down and the HP logo facing you.
6 From the HP Precisionscan Pro software, click the Scan menu,
and select XPA (Slides).
7 Before making any changes, see "Making optional adjustments for
slides or negatives" on page 83 .
8 When you have finished using the XPA light source, on the Scan
menu, click Scanner Glass. Disconnect the XPA light source if you
want.
Tip
The XPA light source also functions as a light table
for viewing 35 mm slides. Insert slides as shown
above.
To keep the XPA light source on beyond the default
period, select the Faster Scan setting in the HP
Scanjet Controls control panel. See "Setting
scanner lamp controls" on page 107 .
