DL.1 User Manual
Fixture Operation
3-5
3
TEST OPTIONS
MENU
HOME FIXTURE:
ALL
Homes the projector head
COPY BOOT:
NO
Safe position: no action when selected
YES
Copies boot code to fixture
SELF TEST
MENU:
CHASSIS
TEST MENU:
PAN
Performs and displays all self test functions
sequentially in the format:
STEP:## DMX:###
TILT
IRIS
FOCUS
ZOOM
INFORMATION
MENU
UNIQUE NUMBER
##########
Displays fixture’s unique number
DMX
VALUES MENU
BY CHANNEL
1:XXX XXX XXX
4:XXX XXX XXX
Displays current values for Link Channels
001– 512 with 6 DMX values/screen. The
first number in the line is the first channel #
with a value displayed on that line.
X:XXX XXX XXX
X:XXX XXX XXX
TEMPERATURES
MENU
CURRENT
INTAKE ####
Displays current temperature of selected
sensor in centigrade
LAMP ####
PANEL #####
MINIMUM
INTAKE MAX #### Displays minimum temperature of selected
sensor in centigrade
LAMP MAX ####
PANEL MAX #####
MAXIMUM
INTAKE MIN ### Displays maximum temperature of selected
sensor in centigrade
LAMP MIN ####
PANEL MIN ####
RESET
NO
Default “safe” setting
YES
Press
sensors to current temperature
FIXTURE HOURS
###:##
Displays fixture operation time in
hours:minutes
FIXTURE HOURS RESET:
NO
Default “safe” setting
YES
Press Enter for 5 seconds to reset fixture
hours to 0
LAMP HOURS:
###:##
Displays lamp operation time in
hours:minutes
PROJECTOR STATUS
XXXXXX
ON
Displays the Projector Status
STANDBY
PROJ HOURS RESET
0
Displays the number of times Projector
Lamp hours have been reset to 0
SOFTWARE VERSION
VER XX.XX.XX
Display current Fixture software version
Major.Minor.Build
MODULE VERSIONS MENU
PAN 2 * 3 PHASE
HW: XXX SW:XX
Displays the available Hardware and
Software versions for each board .
TILT 2 * 3 PHASE
HW: XX SW:XX
RS232 INTERFACE
HW: XX SW:XX
FAN CONTROL
HW: XX SW:XX
ZOOM-FOCUS-IRIS
HW: XX SW:XX
DISPLAY
DISPLAY ERRORS
MENU
XXXXXXXXXXXXXXX
XXXXXXXXXXXXXXX
Scrolls through errors displayed in
2-line, 16-character format
Level 1
Level 2
Level 3
Option/Setting
Description/Notes
enters /exits Menu System and moves up
levels
moves between items on same
level.
selects
scrolls between values
selects
