72

6) Remove the two Thumbscrews, Plate, and Gasket at the top of the Ice Chute, and then

remove the Bin Control Assembly by sliding it slightly toward the Spout and lifting it off.

7) Disassemble the Bin Control Assembly by removing the two Snap Pins, Shaft and

Activator.

8) Remove the three Thumbscrews and the Spout.

9) Remove the Rubber O-ring and Nylon Ring at the top of the Cylinder.

10) Soak or wipe the removed parts.

11) Rinse these parts thoroughly.

IMPORTANT

If the solution is left on these parts, they will rust.

12) Replace the removed parts and the panels.

13) Turn on the power supply and run the icemaker.

14) Turn off the power supply after 30 minutes.

15) Pour warm water into the Storage Bin to melt all ice, and then clean the Bin Liner with

the solution.

16) Flush out any solution from the Storage Bin.

17) Turn on the power supply and start the automatic icemaking process.

IMPORTANT

1. After cleaning, do not use ice made from the sanitizing solution. Be careful

not to leave any solution in the Storage Bin.

2. Follow carefully any instructions provided with the bottles of cleaning or

sanitizing solution.

3. Never run the icemaker when the Reservoir is empty.
