Water Supply
Inlet

Junction Box

Hot Gas
Valve

Solenoid Valve

Heat
Exchanger

Control Water Valve

Bin Control

Ice Chute

Evaporator

Expansion
Valve

Flush Water
Valve

Control Box

Gear Motor

F-1000MLF/-C
