12
F-1000MLF-C
AC SUPPLY VOLTAGE 115/60/1
GEAR MOTOR 120 V 1.6 FLA 1/6 HP
OTHER 120 V 0.03A
MAXIMUM FUSE SIZE 15 A
MAX. HACR BREAKER (USA ONLY) 15 A
MAX. CIRC. BREAKER (CANADA ONLY) 15 A
MINIMUM CIRCUIT AMPACITY 15 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (F)
PER 24 HR. Temp. (F) 50 70 90
lbs./day ( kg/day ) 70 1020 (463) 945 (428) 915 (415)
This data is for reference only, 80 885 (402) 860 (390) 835 (378)
different condensing unit will vary data. 90 805 (366) 795 (361) 760 (344)
100 735 (333) 710 (323) 640 (290)
SHAPE OF ICE Cubelet
ICE QUALITY Approx. 80%, Ice (90/70°F, Conductivity 200 µs/cm)
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 135 (0.40) 135 (0.32)
POTABLE WATER 95 (12) 122 (12)
gal./24HR (gal./100 lbs.)
EXTERIOR DIMENSIONS (WxDxH)
22" x 27-3/8" x 25-1/4" (560 x 695 x 642mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 110 lbs. ( 50 kg ), Shipping 137 lbs. ( 62 kg )
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT
- REFRIGERATION Outlet (Vapor) line 1-1/16-12 UNF Fitting (#10 AEROQUIP)
CIRCUIT Inlet (Liquid) line 5/8-18 UNF Fitting (#6 AEROQUIP)
ICE MAKING SYSTEM Auger type
HARVESTING SYSTEM Direct Driven Auger ( 1/6 HP Gear Motor )
ICE MAKING WATER CONTROL Float Switch
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Mechanical Bin Control ( Proximity Sw. )
CONDENSING UNIT Required refrigeration capacity for ice maker is 5700 BTU/h
at discharge pressure 213 PSIG and suction pressure
31.2 PSIG with R-404A refrigerant.
Suction pressure needs to be 31.2 PSIG.
EVAPORATOR Copper Tube on Cylinder
REFRIGERANT CONTROL Thermostatic Expansion Valve
Evaporator Pressure Regulator
REFRIGERANT CHARGE R-404A, 3.6 oz. (100g Holding Charge)
DESIGN PRESSURE High 427 PSIG, Low 230 PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-off Relay
COMPRESSOR PROTECTION Internal Protector
GEAR MOTOR PROTECTION Manual reset Circuit Breaker or Fuse
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch and Timer
ACCESSORIES -SUPPLIED Spare Fuse
-REQUIRED Ice Storage Bin
OPERATING CONDITIONS VOLTAGE RANGE 104-127 V
AMBIENT TEMP. 45-100° F
WATER SUPPLY TEMP. 45-90° F
WATER SUPPLY PRESSURE 10-113 PSIG
DRAWING NO. (DIMENSION) 3A0984
We reserve the right to make changes in specifications and design without prior notice.
