F-1000MWF/-C

Water Supply
Inlet

Junction Box

Water
Regulator

Compressor

Drier

Control Water Valve

Bin Control

Ice Chute

Evaporator

Expansion
Valve

Flush Water
Valve

Control Box

Gear Motor
