11. Unplug the Bluetooth cable from the Bluetooth module, and then remove the holder assembly
from the computer.
12. Remove the Bluetooth module from the holder by pulling on the small arm at the mouth of the
holder, and then sliding the module out of the holder.
To install the Bluetooth module, reverse the removal procedures.
Optical drive
CD and DVD media can be removed from the optical drive manually, even if the system is not
running.
1. Prepare the computer for disassembly (see Preparing to disassemble the HP TouchSmart PC
on page 11 ).
2. Place the computer face down on a soft, flat surface.
3. Remove the hard drive/memory cover (see Hard drive/memory cover on page 12 ).
4. Remove the stand (see Stand on page 15 ).
5. Remove the I/O cover (see I/O cover on page 13 ).
6. Remove the feet (see Feet on page 14 ).
7. Remove the back cover (see Back cover on page 20 ).
8. Disengage the optical drive eject button connector from the cable guide at the side of the optical
drive cage.
9. Loosen the captured screw that secures the optical drive cage to the computer (1).
Optical drive 35
