Heat & Glo LifeStyle Collection • Twilight-II-B • 2108-900 Rev. G • 8/07 9
C. Mantel Projections - Indoor only
Figure 3.4 Indoor Clearances to Mantels or other
Combustibles
above Appliance
Figure 3.5 Indoor clearances to Mantel Legs or Wall
Projections (Acceptable on both sides of opening.)
12
11
10
9
8
7
6
13-5/8
12-5/8
11-5/8
10-5/8
9-5/8
8-5/8
7-5/8 HOOD
NON-COMBUSTIBLE BOARD
(SUPPLIED ON APPLIANCE)
INDOOR SIDE ONLY
CEILING
35-3/4
MEASURED
FROM CORNER
TOP VIEW
FIREPLACE
HOOD
½ IN.
Note: Measurements are in inches.
