Heat & Glo LifeStyle Collection • Twilight-II-B • 2108-900 Rev. G • 8/07
7
GLASS
FLUSH TO EXTERIOR INSULATED ENVELOPE
GLASS
A
B
B
D
E
C
B
GLASS
FLUSH TO EXTERIOR INSULATED ENVELOPE
GLASS
NOTE:
• Illustrations reflect typical installations and are FOR
DESIGN PURPOSES ONLY.
• I
llustrations/diagrams are not drawn to scale.
• Actual installation may vary due to individual design
preference.
Fire Risk
Provide adequate clearance:
• Around air openings
• To combustibles
• For service access
Locate appliance away from traffi c areas.
A. Selecting Appliance Location
When selecting a location for your appliance it is important to
consider the required clearances to walls (see Figure 3.1).
Figure 3.1 Appliance Locations
NOTE: For actual appliance dimensions refer to Section
13.
In addition to these framing dimensions, also reference the following section:
• Clearances and Mantel Projections (Sections 3.B and 3.C)
WARNING
A
B
C
D
E
Minimum
Minimum
-
Minimum
-
Inches
43 1/2
24
36
43
Millimeters
1092.2
12.7
609.6
914.4
1092.2
3
3
Framing and Clearances
