HP Media Gateways G250 - Manual (Page 71)

Issue 5 June 2008 71
Appendix D: G350 technical specifications
The G350 technical specifications include physical dimensions and tolerances of the Avaya
G350 Media Gateway, power cord specifications, and media module specifications.
G350 specifications
The table of technical specifications provides detailed information on the physical dimensions
and tolerances of the Avaya G350 Media Gateway:
Table 18: Avaya G350 Media Gateway specifications
Description Value
Height 5.25 in. (133.3 mm)
Width 19 in. (482.6 mm)
Depth 15.75 in. (400 mm)
Weight of empty chassis 19.8 to 22.1 lb. (9 to 10 kg)
Ambient working temperature 32
° to 104°F (0° to 40°C)
Operation altitude up to 6,560 ft. (2000 m)
Front Clearance 12 in. (30 cm)
Rear Clearance 18 in. (45 cm)
Humidity 10-90% relative humidity
Power rating 90-264 VAC, 47-63 Hz, 7 A Max
