Supported media modules in the G350
Issue 5 June 2008
33
MM316 LAN media module
The MM316 LAN media module provides:
●
40 Ethernet 10/100 Base-T Ethernet access ports with inline Power over Ethernet (PoE)
●
One Gigabit Ethernet copper port for server connection or uplink to another switch or
router
The MM316 supports 48V DC inline power provided over standard category 5 UTP cables (up
to 100m range) on each PoE port.
Power consumption for the MM316 media module is 435W.
MM316 features
●
Priority power budgeting with configurable priorities
●
Automatic load detection on ports
●
Automatic device discovery
●
Enable/disable port powering option
●
Port monitoring
●
Automatic recovery from overload shutdown
●
Automatic recovery from no-load shutdown
Figure 20: The MM316 media module
The MM316 is compatible with Avaya CM version 2.0 and higher, and G350 firmware version
25.0.0 and higher.
For more information about PoE, see
