Issue 5 June 2008 69
Appendix C: G250 technical specifications
The G250 technical specifications include physical dimensions and tolerances of the Avaya
G250 Media Gateway, power cord specifications and media module specifications.
G250 specifications
The table of technical specifications provides detailed information on the physical dimensions
and tolerances of the Avaya G250 Media Gateway:
Table 16: Avaya G250 Media Gateway specifications
Description Value
Height 20 (3.5 in., 88 mm)
Width 17.3 in. (440 mm)
Depth 13.4 in. (340 mm)
Weight of empty chassis 16.5 lb. (6.5 kg)
Ambient working temperature 32
° to 104°F (0° to 40°C)
Operation altitude up to 6,560 ft. (2,000 m)
Front Clearance 12 in. (30 cm)
Rear Clearance 18 in. (45 cm)
Humidity 10-90% relative humidity
Power rating 90-264 VAC, 47-63 Hz, 2.2 A Max
