1740 SHDSL 2/4-Wire Router User’s Guide
To configure the advance functions of the RIP, click on the RIP tab on the main screen, and configure the
requested parameters.
Mode: Select Enabled
Version: RIP version 2 or version 1
Authentication: none: no authentication code is required.
PlainText: an authentication code is required. You should also fill in
the Authentication Code field to assign a password.
MD5: an authentication code is required. You should also fill in the
Authentication Code field to assign a password.
48 September 2004 1740-A2-GB20-10
