FUNCTION COMMAND Color
LJ
Color
LJ 5,
5M
4LJ
Pro
4LC 5L
6L 5P
5MP
6P
6MP
5Si
5SiMx
Mopier
5
5M
4000
series
Desk-
Jet
1200C
Desk-
Jet
1600C
RASTER GRAPHICS
Raster Resolution ?*t#R
75 Dots/Inch (75) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
100 Dots/Inch (100) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
150 Dots/Inch (150) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
200 Dots/Inch (200)
1
ns ns ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ns ✓
300 Dots/Inch (300) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
600 Dots/Inch (600)
1
ns ns ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ns ✓
Graphics Presentation ?*r#F ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Raster Height (Source) ?*r#T ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Raster Height (Destination) ?*t#V ✓ ✓ ns ns ns ns ns ns ns ns ✓ ✓
Raster Width (Source) ?*r#S ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Raster Width (Destination) ?*t#H ✓ ns ns ns ns ns ns ns ns ns ✓ ✓
Scale Algorithm ?*t#K ns ✓ ns ns ns ns ns ns ns ns ✓ ✓
Start Raster Graphics ?*r#A
At logical page left limit(0) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
At CAP (1) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
At logic. page left limit,
scaling ON (2) ✓ ✓ ns ns ns ns ns ns ns ns ✓ ✓
At CAP, scaling ON (3) ✓ ✓ ns ns ns ns ns ns ns ns ✓ ✓
Y Offset ?*b#Y ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Set Compression Mode ?*b#M
Unencoded (0) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Run-Length Encoded (1) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
TIFF Encoded (2) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Delta Row Encoded (3) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Mode 5 Adaptive (5) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Replacement Delta Row (9) ns ns ns ns ns ns ns ns ns ns ns ✓
Transfer Raster (Row/Block) ?*b#W[data] ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Transfer Raster (Plane) ?*b#V[data] ✓ ✓ ns ns ns ns ns ns ns ns ✓ ✓
End Graphics
Version B ?*rB ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
Version C (Preferred) ?*rC ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
✓ - Indicates a command is supported. ns - Indicates a command is not supported.
1
Supported if printer resolution is 600 dpi.
Table 1-1. PCL 5 Feature Support Matrix (continued)
Feature Set 1-17
