Table a-1. hp pcl 5 commands (continued) – HP 4 FAMILY User Manual
Page 192
FUNCTION
PARAMETER
COMMAND
DECIMAL VALUE
HEXADECIMAL VALUE
COLOR COMMANDS
Assign Color Index
Index Number
?*v#I
(i)
027 042 118 #...# 073
(105) 1B 2A 76 #...# 49
(69)
Color Component One
1st Component
?*v#A
(a)
027 042 118 #...# 065
(97)
1B 2A 76 #...# 41
(61)
Color Component Two
2nd Component
?*v#B
(b)
027 042 118 #...# 066
(98)
1B 2A 76 #...# 42
(62)
Color Component Three
3rd Component
?*v#C
(c)
027 042 118 #...# 067
(99)
1B 2A 76 #...# 43
(63)
Color Lookup Tables
# of Bytes
?*l#W[Data]
027 042 108 #...# 087
1B 2A 6C #...# 57
Configure Image Data
# of Bytes
?*v#W[Data]
027 042 118 #...# 087
1B 2A 76 #...# 57
Download Dither Matrix
# of Bytes
?*v#I
(i)
027 042 118 #...# 073
(105) 1B 2A 76 #...# 49
(69)
Foreground Color
Index Number
?*v#S
(s)
027 042 118 #...# 083
(115)
1B 2A 76 #...# 53
(73)
Gamma Correction
Gamma Number
?*t#I
(i)
027 042 116 #...# 073
(105) 1B 2A 74 #...# 49
(69)
Monochrome Print Mode
Mixed Rendering
?&b0M
(m) 027 038 062 048 077
(109) 1B 26 98 30 4D
(6D)
Gray Equivalent
?&b1M
(m) 027 038 062 049 077
(109) 1B 26 98 31 4D
(6D)
Palette Control ID
Palette ID #
?&p#I
(i)
027 038 112 #...# 073
(105) 1B 26 70 #...# 49
(69)
Palette Control
Delete All Palettes in store
?&p0C
(c)
027 038 112 048 067
(99)
1B 26 70 30 43
(63)
Delete All Palettes in stack
?&p1C
(c)
027 038 112 049 067
(99)
1B 26 70 31 43
(63)
Delete Palette (last ID)
?&p2C
(c)
027 038 112 050 067
(99)
1B 26 70 32 43
(63)
Copy Palette
?&p6C
(c)
027 038 112 054 067
(99)
1B 26 70 36 43
(63)
Push/Pop Palette
Push Palette
?*p0P
(p)
027 042 112 048 080
(112)
1B 2A 70 30 50
(70)
Pop Palette
?*p1P
(p)
027 042 112 049 080
(112)
1B 2A 70 31 50
(70)
Render Algorithm
Continuous tone detail
?*t0J
(j)
027 042 116 048 074
(106) 1B 2A 74 30 4A
(6A)
Snap to primaries
?*t1J
(j)
027 042 116 049 074
(106) 1B 2A 74 31 4A
(6A)
Snap black/white, colors to black
?*t2J
(j)
027 042 116 050 074
(106) 1B 2A 74 32 4A
(6A)
Device best dither
?*t3J
(j)
027 042 116 051 074
(106) 1B 2A 74 33 4A
(6A)
Error diffusion
?*t4J
(j)
027 042 116 052 074
(106) 1B 2A 74 34 4A
(6A)
Monochrome device best dither
?*t5J
(j)
027 042 116 053 074
(106) 1B 2A 74 35 4A
(6A)
Monochrome error diffusion
?*t6J
(j)
027 042 116 054 074
(106) 1B 2A 74 36 4A
(6A)
Cluster ordered dither
?*t7J
(j)
027 042 116 055 074
(106) 1B 2A 74 37 4A
(6A)
Monochrome cluster ordered
?*t8J
(j)
027 042 116 056 074
(106) 1B 2A 74 38 4A
(6A)
User-defined dither
?*t9J
(j)
027 042 116 057 074
(106) 1B 2A 74 30 4A
(6A)
Monochrome user-defined dither
?*t10J
(j)
027 042 116 049 048 074 (106) 1B 2A 74 31 30 4A
(6A)
Ordered dither
?*t11J
(j)
027 042 116 049 049 074 (106) 1B 2A 74 31 31 4A
(6A)
Monochrome ordered dither
?*t12J
(j)
027 042 116 049 050 074 (106) 1B 2A 74 31 32 4A
(6A)
Noise ordered dither
?*t13J
(j)
027 042 116 049 051 074 (106) 1B 2A 74 31 33 4A
(6A)
Monochrome noise ordered dither ?*t14J
(j)
027 042 116 049 052 074 (106) 1B 2A 74 31 34 4A
(6A)
Continuous tone smooth
?*t15J
(j)
027 042 116 049 053 074 (106) 1B 2A 74 31 35 4A
(6A)
Mono. continuous tone detail
?*t16J
(j)
027 042 116 049 054 074 (106) 1B 2A 74 31 36 4A
(6A)
Mono. continuous tone smooth
?*t17J
(j)
027 042 116 049 055 074 (106) 1B 2A 74 31 37 4A
(6A)
Continuous tone basic
?*t18J
(j)
027 042 116 049 056 074 (106) 1B 2A 74 31 38 4A
(6A)
Mono. continuous tone basic
?*t19J
(j)
027 042 116 049 057 074 (106) 1B 2A 74 31 39 4A
(6A)
Select Palette
Palette ID #
?&p#S
(s)
027 038 112 #...# 083
(115)
1B 26 70 #...# 53
(73)
Set Viewing Illumination
# of Bytes
?*i#W[Data]
027 042 105 #...# 087
1B 2A 69 #...# 57
Simple Color
3-Plane Device CMY Palette
?*r–3U
(u)
027 042 114 045 051 085 (117)
1B 2A 72 2D 33 55
(75)
1-Plane K Palette
?*r1U
(u)
027 042 114 049 085
(117)
1B 2A 72 31 55
(75)
3-Plane Device RGB Palette
?*r3U
(u)
027 042 114 051 085
(117)
1B 2A 72 33 55
(75)
Table A-1.
HP PCL 5 Commands (continued)
A-18 Printer Commands
