Operations 25
Install the PCI riser cage
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser cage.
1. Align the PCI riser cage with the chassis and slide it into place.
2. Tighten the thumbscrews to secure the PCI riser cage:
a. Press down the black knob while turning clockwise, until fully tightened.
b. While holding the black knob and pressing down, press and release the blue button to lower the
black knob to the locked position.
3. Connect any required internal cables to the expansion board. Refer to the documentation that ships
with the expansion board.
4. Install the access panel (on page 24 ).
5. Install the server into the rack.
