Page 41
2-23
Installing the Switch
Sample Network Topologies
In
sta
lli
ng th
e Swi
tch
Resiliency Using 6400cl Series as a meshed Cluster
The redundant topology increases the availability of a single switch by
protecting against single points of failure. All hardware and paths are
redundant and active (versus, Spanning Tree Blocking). If any hardware
failure occurs, I/O communications can still be completed through another
path.
To Server or other
Switches (Not
meshed ports)
To Server or other
Switches (Not
meshed ports)
ProCurve Switch 6400cl
ProCurve Switch 3400cl
10-GbE Cables
10-GbE Cables
