Front of the switch, Front of the switch -3 – HP 6400CL User Manual
Page 11
1-3
Introducing the Switch
Front of the Switch
In
trodu
cin
g
the
Sw
it
ch
Front of the Switch
Reset and Clear
buttons
Switch port LEDs
Power
and Fault
LEDs
Console port
ProCurve Switch 10-Gig 6400cl-6XG (J8433A)
Test, Fan, RPS, and
Module Status LEDs
Auxiliary port
LED
Auxiliary port
Network ports
Test, Fan, RPS, and
Module Status LEDs
ProCurve Switch 10-Gig 6410cl-6XG (J8474A)
Console port
Auxiliary port
LED
Auxiliary port
Switch port LEDs
Power
and Fault
LEDs
Reset and Clear
buttons
Media Flex X2 transceiver slots
