Supplemental Characteristics
Table A-2 lists the supplemental characteristics, which are not warranted but are descriptions of
typical performance determined either by design or type testing.
Table A-2. Supplemental Characteristics
Parameter HP 6631B HP 6632B
HP 66332A HP 6633B HP 6634B
Input Ratings
(at full load) 100 Vac mains:
115 Vac mains:
220 Vac mains:
230 Vac mains: 87
−
106 Vac, 47
−
63 Hz, 3.5 A, 250 W
104
−
127 Vac, 47
−
63 Hz, 3 A, 250 W
191
−
233 Vac, 47
−
63 Hz, 1.6 A, 250 W
207
−
253 Vac, 47
−
63 Hz, 1.5 A, 250 W
Output Programming
Range Voltage:
Current:
OVP:
0-8.190 V
0-10.237A
0-12V
0
−
20.475 V
0
−
5.1188 A
0
−
22 V
0
−
51.188 V
0
−
2.0475 A
0
−
55 V
0
−
102.38 V
0
−
1.0238 A
0
−
110 V
Average Programming
Resolution Voltage:
Current:
OVP:
2 mV
2.5 mA
60 mV
5 mV
1.25 mA
100 mV
12.5 mV
0.5 mA
250 mV
25 mV
0.25 mA
500 mV
OVP Accuracy 2.4% + 100 mV 2.4% + 240 mV 2.4% + 600 mV 2.4% + 1.2 V
Maximum Current
Measurement 14.3 A 6.66 A 2.43 A 1.21 A
Average Current
Measurement Resolution High Range:
Low Range:
436 uA
0.6 uA
213
µ
A
0.6
µ
A
74
µ
A
0.6
µ
A
37
µ
A
0.6
µ
A
Sink Current -10 A −
5 A
−
2 A
−
1 A
Sink Current Tracking SCPI mode 1 :
Compatibility mode:
0.4% + 4 mA
-500 mA
0.4% + 2 mA
−
250 mA
0.4% + 1 mA
−
100 mA
0.4% + 0.5 mA
−
50 mA
Minimum Current in
Compatibility Mode 40 mA 20 mA 8 mA 4 mA
Programming Accuracy
Temperature Coefficient
(change/
°
C)
Voltage:
Current:
OVP:
0.01% + 0.15 mV
0.01% + 60 uA
0.01% + 2 mV
0.01% +0.25 mV
0.01% + 30
µ
A
0.015% + 4 mV
0.01% + 0.5 mV
0.01% + 12
µ
A
0.015% + 10 mV
0.01% + 1 mV
0.01% + 6
µ
A
0.015% + 20 mV
Readback Accuracy
Temperature Coefficient
(change/
°
C)
Voltage:
Current (ACDC):
Current (DC):
Current (Low range):
0.01% + 60 uV
0.05% + 320 uA
0.02% + 50uA
0.01% + 0.3 uA
0.01% + 150
µ
V
0.05% + 160
µ
A
0.02% + 25
µ
A
0.01% + 0.3
µ
A
0.01% + 500
µ
V
0.05% + 80
µ
A
0.02% + 10
µ
A
0.01% + 0.3
µ
A
0.01% + 750
µ
V
0.05% + 40
µ
A
0.02% + 5
µ
A
0.01% + 0.3
µ
A
Drift 2 Voltage:
Current:
0.01% + 0.25 mV
0.01% + 100uA
0.01% + 0.5 mV
0.01% + 50
µ
A
0.01% + 1 mV
0.01% + 20
µ
A
0.01% + 1 mV
0.01% + 10
µ
A
Output Voltage Rise/Fall
Time Normal mode:
Fast mode:
2 ms
400
µ
s
(for a change from 10% to 90% or 90% to 10% of the total excursion)
Output Voltage Settling
Time Normal mode:
Fast mode:
6 ms
2 ms
(to settle within 1 LSB or 0.025% times the rated voltage of the final value)
1 For 8 volt unit, between 0 and 10 mA, the sink current remains at –10 mA.
For 20 volt unit, between 0 and 5mA, the sink current remains at –5 mA.
For 50 volt unit, between 0 and 2.5 mA, the sink current remains at –2.5 mA.
For 100 volt unit, between 0 and 1.25 mA, the sink current remains at –1.25 mA.
2
Following a 30 minute warm-up, the change in output over 8 hours, under ambient temperature,
constant load, and line operating conditions.
