Table B- 5. Verification Test Record for HP 6633B
Model HP 6633B Report No.____________ Date_____________
Test Description Minimum
Specification
Recorded Results Maximum
Specification
Voltage Programming and Measurement
Low Voltage V
out
−
20 mV _______V +20 mV
Front Panel measurement V
out
−
6 mV _____mV V
out
+6 mV
High Voltage V
out
49.955 V _______V 50.045 V
Front Panel measurement V
out
−
21 mV _____mV V
out
+21 mV
Current Programming and Measurement (High Range)
Low Current I
out
−
1 mA _______A 1 mA
High Current I
out
1.998 A _______A 2.002 A
Front Panel measurement I
out
−
4.25 mA _____mA I
out
+4.25 mA
Current Measurement (Low Range)
Low Current measurement I
out
−
2.5
µ
A _____
µ
A I
out
+2.5
µ
A
High Current measurement I
out
−
22.5
µ
A _____
µ
A I
out
+22.5
µ
A
Current Sink Measurement
Low Current Sink measurement I
sink
−
22.5
µ
A _____
µ
A I
sink
+22.5
µ
A
High Current Sink measurement I
sink
−
4.85 mA _____mA I
sink
+4.85 mA
Table B- 6. Verification Test Record for HP 6634B
Model HP 6634B Report No.____________ Date_____________
Test Description Minimum
Specification
Recorded Results Maximum
Specification
Voltage Programming and Measurement
Low Voltage V
out
−
50 mV _______V +50 mV
Front Panel measurement V
out
−
12 mV _____mV V
out
+12 mV
High Voltage V
out
99.90 V _______V 100.10 V
Front Panel measurement V
out
−
42 mV _____mV V
out
+42 mV
Current Programming and Measurement (High Range)
Low Current I
out
−
0.5 mA _______A 0.5 mA
High Current I
out
0.999 A _______A 1.001 A
Front Panel measurement I
out
−
2.25 mA _____mA I
out
+2.25 mA
Current Measurement (Low Range)
Low Current measurement I
out
−
2.5
µ
A _____
µ
A I
out
+2.5
µ
A
High Current measurement I
out
−
22.5
µ
A _____
µ
A I
out
+22.5
µ
A
Current Sink Measurement
Low Current Sink measurement I
sink
−
22.5
µ
A _____
µ
A I
sink
+22.5
µ
A
High Current Sink measurement I
sink
−
2.85 mA _____mA I
sink
+2.85 mA
