5 - Front Panel Operation
40
Output Control Keys
Output control keys control the output functions of the dc source.
Press this key to access the voltage menu.
Display Command Function
VOLT Sets the output voltage
Press this key to access the current menu.
Display Command Function
CURR Sets the output current
Press this key to access the output menu list.
Display Command Function
*RST Places the dc source in the factory-default state
PON:STATE Select the power-on state command (RST or RCL0) 1
RI Sets the remote inhibit mode (LATCHING, LIVE, or OFF) 1
DFI Sets the discrete fault indicator state (ON or OFF)
DFI:SOUR Selects the DFI source (QUES, OPER, ESB, RQS, or OFF) 2
PORT Sets the output port functions (RIDFI or DIGIO)
1
DIGIO Sets and reads the I/O port value (0 through 7)
RELAY Set relay state independent of output (``ON'' or ``OFF'')
REL:POL Set relay polarity (``NORM'' or ``REV'').
PROT:DLY Sets the output protection delay in seconds
Press this key to display protection status.
Display Command Function
OC OT OV RI FS Status of the protection features (example shows all tripped)
-- -- -- -- -- Status of the protection features (example shows none
tripped)
Press this key to access the overvoltage protection menu.
Display Command Function
VOLT:PROT Sets overvoltage protection level
This key accesses the calibration menu (Refer to Appendix B to calibrate your dc
source).
Notes:
1
These parameters are stored in non-volatile memory
2 These status summary bits are explained in chapter 3 of the Programming Guide
value = a numeric value
char = a character string parameter
Use and to scroll through the menu commands.
Use and to scroll through the menu parameters.
Use and to select a digit in a numeric entry field.
Voltage
Current
Output
Protect
OV Shift
Cal Shift
q p
г
д
б в
