Page 28 For technical questions, please call 1-800-444-3353. SKU 93793
part Description
1 Side Panel
2 Gas Line
3 Chain
4 Gas Bottle Support
5 Back Panel
6 Rubber Support
7 Top Panel
8 Hinge
9 Rubber Washer
10 Nut, M8
11 Inner Panel
12 Fan
13 10 lb. Spool Axle
14 10 lb. Spool Clip
15
Wire Feed Mechanism
(includes parts 15a-15j, & 16)
15a Swing Arm
15b Tension Adjusting Knob
15c Tensioning Arm
15d Tension Spring
15e Tension Pusher
15f Wire Feed Leader
15g Screw
15h Cable Clamp
15i Feed Roller Bracket
15j Screw
16 Wire Feed Wheel (0.6 & 0.8 mm)
17 Knob
18 Copper Washer
19 Washer
20 Insulating Washer
21 Insulating Washer
22 Copper Washer
23 Copper Nut, M8
24 Washer
25 Copper Bolt, M8
26 Cable Tip
27 Rectifier Rack
28 Bolt, M10 x 25
29 Lock Washer
30 Washer
31 Access Panel
32 Latch
part Description
33 Filter Reactor
34 Main Transformer
35 Transformer Carriage
36 Bottom Panel
37 Caster
38 Thermal Switch Bracket
39 Thermal Switch
40 Axle Bracket
41 Cotter Pin
42 Washer
43 Wheel
44 Axle
45 Handle
46 Right Handle Socket
47 Grommet
48 Grommet
49 Wire Speed Control Knob
50 Overload Indicator Light
51 Welding Torch/Cable Assembly
51a Nozzle
51b Contact Tip (.8 mm)
51c Head Tube
51d Switch Box
51e Trigger
51f Control Switch
51g Liner and Fitting
51h Gas Hose (white)
51i Power Cable (black)
51j Right Torch Housing
51k Left Torch Housing
51l Screw
51m Protective Sleeve
52 Ground Clamp
53 Ground Cable
54 Line Cord
55 Voltage Control Knob
56 Cable Tip
57 Front Panel
58 Left Handle Socket
59 Voltage Control
60 Circuit Board
61 Circuit Board Bracket
parts list
