35
RECORD
OUTDOOR TEMPERATURE ______°F
SYSTEM VOLTAGE ______Volts ______PH ______Hz
Cooler compressor amps ______L1 ______L2 ______L3
Freezer compressor amps ______L1 ______L2 ______L3
Cooler discharge pressure ______PSIG
Freezer discharge pressure ______PSIG
Cooler suction pressure ______PSIG
Freezer suction pressure ______PSIG
Cooler suction temp. ______°F
Freezer suction temp. ______°F
Cooler refrigerant charge ______lbs.
Freezer refrigerant charge ______lbs.
Cooler compressor superheat ______°F
Freezer compressor superheat ______°F
Cooler evaporator superheat ______°F
Freezer evaporator superheat ______°F
Cooler discharge temp. ______°F
Freezer discharge temp. ______°F
™
Service Record
