Dimensions – Hubbell Euclid Series 2017 User Manual
Page 9
9
Dimensions
2
0
1
5
/1
6
/1
7
Figure 4
Type SWPBC,
NEMA 3/4/13
Enclosure
Surface Mounting
6.00"
5.88"
2.00"
0.5"
"A"
"B"
Pipe
Size
0.63" Mtg. Hole (2)
6.00"
6.12"
2.00"
"B"
Pipe Size
5.88"
0.12"
0.75"
6.50"
0.5"
7.50"
"A"
"C"
0.44"ø Mtg. Hole (4)
Figure 5
Type XPBC,
NEMA 7
Enclosure
Figure 6
Type SXPBC,
NEMA 7
Enclosure
Surface Mounting
6.00"
5.88"
2.00"
0.5"
"A"
"B"
Pipe Size (2)
0.63" Mtg. Hole (2)
8.5"
6.00"
14.5"
Figure 7
Type 2XPBC,
NEMA 7
Enclosure
Duplex
4.00"
2.12"
4.00"
0.44"
4.88"
2.00"
2.75"
0.75"
0.38"
0.12"
"C"
"B"
Pipe
Size
0.34"ø Mtg.
Hole (4)
All dimensions are approximate and
are not for construction purposes.
9
440/428-1161 • Fax 440/428-7635
HUBBELL
hubbell industrial controls, inc.
This manual is related to the following products:
