3
Diagrams & Dimensions
20
01
3.625"
2.625"
"B"
"A"
"P" Pipe
Size
No. of
“A”
“B”
“P”
Approx.
Fig.
Buttons
Wt. (lbs.)
Type HD Pendant – NEMA
1
2
6.31"
0.56"
0.75"
2.00
1
4
10.00"
0.56"
0.75"
3.75
1
6
13.75"
1.63"
1.00"
4.75
1
8
17.37"
2.00"
1.25"
6.00
1
10
21.12"
2.00"
1.25"
7.50
1
Figure 1
Type HD
NEMA 1
*
Pushbutton
Inserts
Single Speed or
Momentary Start-Stop
Cat# J1/J1A & K1/K1A
Two Speed
Cat# J2/K2
Maintained Start-Stop
Cat#JM/KM
Maintained/
Momentary Lift/Dr
op
Cat# JN/KN
Toggle Switch
Cat# JT
Pilot Light
Cat# JP1/JP5 & KP1/KP5
Momentary Reset
Cat# JR/KR
FWD
REV
UP
DOWN
Low Speed
High Speed
START
STOP
LIFT
DROP
Maintained
Momentary
OFF
ON
Toggle Switch
R
Pilot Light
Reset
Contact Ratings
Single Br eak
AC
DC
NEMA
A300
NEMA
P300
*
OSHA limits pendant voltage
to 150VAC or 300VDC
120V
240V *
6A
3A
125V
250V
1.1A
0.55A
3
