Hubbell Euclid Series 2017 - Manual (Page 11)

11
Specifications
2
0
2
0
Hard Rubber Guard
Button Cover
Plug-In Insert
Terminal Base
Back Cover
Universal Hanger
Bracket
Pilot Light
Pilot Light
Nameplate
Pilot Lens
Enclosure
Number of Approx.
Buttons ”A” Wt. (lbs.)
2 7.87" 2.5
5 † 13.69" 4.5
7 † 18.00" 5.5
9 † 22.31" 7.0
† Enclosures include extra 30mm hole at top for
pilot light, toggle switch, etc.
(N/A for 2 button case).
3.25" 3.50" 0.88"
"A"
Cable Entrance - Threaded
1" ID, 1.25" OD
0.38" Suspension
Cable Hole (2)
Function
Nameplate
Single Speed
Plug-In Inserts
Momentary N.O.
Cat# PG1
Momentary N.O. & N.C.
Maintained N.O. & N.C.
Maintained/Momentary Lift-Drop
Cat# PG2/3/4
Momentary/Maintained Start-Stop
Momentary Start-Stop/Reset-Stop
Cat# PG5/6
Momentary Stop-Start/Stop-Reset
Cat# PG7
FWD
REV
rear view
top
FWD
REV
rear view
top
START
STOP
rear view
top
STOP
START
rear view
top
Up/Fwd.
Down/Rev.
3 Speed rear view
(for 2 Speed do not use Terminal 3)
3 2 1 1 2 3
3 2 1 1 2 3
(2A)
(F)
(L1)
(1A)
(1A)
(L1)
(R)
(2A)
Jumper by
Customer
1
3
2
4
3
1
4
2
Up/Fwd.
Down/Rev.
5 Speed rear view
(for 4 Speed do not use Terminal 6)
5 4 3 2 1 1 2 3 4 5
5 4 3 2 1 1 2 3 4 5
(4A)
(F)
(L1)
(3A)
(3A)
(2A) (1A)
(1A) (2A)
(L1)
(R)
(4A)
Jumper by
Customer
1
3
5 2
4
6
6
4
2 5
3
1
Dimensions
Contact Ratings –
Single Break
Single Speed Multi Speed
AC
DC
NEMA
A300
NEMA
P300
* OSHA limits pendant voltage to 150VAC or 300VDC
† Closest NEMA rating.
120V
240V* 6A
3A
125V
250V 1.1A
0.55A
AC
DC
NEMA
A300
NEMA
R300 †
120V
240V* 6A
3A
125V
250V 0.4A
0.2A
Multi-Speed
Plug-In Inserts
Two and Three Speed – Cat# MS2
Four and Five Speed – Cat# MS5
PG4 and PG5 inserts have one
button maintained and one button
momentary. “Off-On” buttons rec-
ommended to comply with provi-
sion of NEMA ICS 3-442.15.
11
