Hubbell Euclid Series 2017 - Manual (Page 16)

16
5 6
3 4
1 2
2 1
4 3
6 5
5 4 3 2 1
5 4 3 2 1
3 2 1 4 5
3 2 1 4 5
Up/Fwd
Down/Rev
Top
Rear View
Jumper by Customer
Symbol Key
M – Maintained Position; S – Spring Return Position
X – Contact Closed; O – Contact Open
Contact Sequence
2
0
4
0
Specifications
Selector & Toggle Switches
Hubbell’s selector switches are available in 2 or 3 position maintained or spring return
operators. Hubbell also has a 2 position toggle switch that is rated at 10 amps.
Circuits Type of Return
Part No.
80321-100
80321-101
80321-301
80321-302
80321-303
80321-304
80321-305
80321-306
Toggle
M
M
M
M
M
M
M
M
M
S
S
M
M
M
M
M
S
M
S
M
M M
Operator
Selector
Selector
Selector
Selector
Selector
Selector
Selector
Illuminated Pilot Lights
Hubbell’s pilot lights are available in either 120VAC/DC or 250VAC/DC and are
constructed to the same standards and quality as the pushbuttons. The pilot light bulb
and lenses are easily removed for maintenance. Additional color lenses are available.
Type of Voltage Lens
Bulb AC/DC Color Part No.
Neon 120V Red 80324-100
Neon 120V Amber 80324-101
Neon 120V Green 80324-102
Incandescent 120V Red 80324-210
Incandescent 120V Amber 80324-211
Incandescent 120V Green 80324-212
Incandescent 250V Red 80324-213
Incandescent 250V Amber 80324-214
Incandescent 250V Green 80324-215
Two Button – Five Speed Element
Hubbell’s two button – five speed element is specifically designed to meet the most severe
conditions. The two buttons are mechanically interlocked which prevents both buttons from
being depressed simultaneously. These switches are ideal for pendant or other control appli-
cations that require multi-speed operation.
No. of No. of Button
Speeds Contacts Color Part No.
6-NO/Button
Five Sequentially Black 80825-000*
Closed
* CSA Approved
440/428-1161 • Fax 440/428-7635
