To remove and replace the mother board
HP 16500B
1
Using previous procedures, remove the following assemblies:
•
Top and bottom covers
•
Power supply
•
Microprocessor board
•
All optional modules and filler panels
2
Set the frame so that the bottom of the frame is facing up. This is to gain access to
the fan power cable and the front-panel cable.
3
Disconnect the fan power cable and the front-panel cable from the mother board.
4
Remove the six mother board mounting screws, then lift the mother board out of the
mainframe.
5
Reverse this procedure to install the replacement mother board.
HP 16501A
1
Using previous procedures, remove the following assemblies:
•
Top and bottom covers
•
Power supply
•
Expansion interface board
•
All optional modules and filler panels
2
Set the frame so that the bottom of the frame is facing up. This is to gain access to
the fan power cable and the front-panel cable.
3
Disconnect the fan power cable from the mother board.
4
Remove the six mother board mounting screws, then lift the mother board out of the
expansion frame.
5
Reverse this procedure to install the replacement mother board.
