still tied low, so in this case it will use the soft name last downloaded. This

will allow drive access without confusing the host.

Field Replaceable Units

An FRU code identifies which part of the hardware is considered to have

failed. These codes turn up in sense data byte 14 and as the sense code

qualifier for sense codes 4400h (internal target failure) and 40XX (diagnostic

failure).
Although there are no actual Field Replaceable Units on HP Ultrium drives, the

following sub-assemblies can be replaced at Repair Centres:

Descriptions of Signals

(Parallel SCSI only)

The SCSI interface consists of 27 signals—9 control lines, 16 data lines and 2

parity lines. A description of these signals is given in the following table.

Drive PCA

Head Assembly

Mechanism

Front Panel

Signal

Name

Driven by

Description

-BSY

Busy

OR-tied signal used to indicate that the SCSI bus is in use.

-SEL

Select

Initiator

Target

Used to select a target during the Selection phase.
Used to select an initiator during the Reselection phase.

-C/D

Control/Data

Target

Indicates whether control or data information is on the data

bus.

True (low)

Control information

False (high)

Data information

-I/O

Input/Output

Target

Controls the direction of data movement on the bus with

respect to the Initiator. This signal is also used to distinguish

between Selection and Reselection phases.
