FPIF-CRT details
The FPIF-CRT allows the VIPER to drive a CRT Monitor or an analogue LCD flat
panel. Sync on green and composite sync monitors are not supported.
The connectors on the following pages are shown in the same orientation as
the picture above, unless otherwise stated.
Connector Function
J1 VIPER LCD cable connector
J2 CRT connector
J2 J1
