VIPER Technical Manual Introduction
© 2007 Eurotech Ltd Issue E 13
Conventions
Symbols
The following symbols are used in this guide:
Symbol Explanation
Note - information that requires your attention.
Tip - a handy hint that may provide a useful alternative or save time.
Caution - proceeding with a course of action may damage your equipment
or result in loss of data.
Indicates that a feature is not available on the standard VIPER-Lite
configuration. Eurotech Ltd can provide custom configurations (subject to a
minimum order quantity) for the VIPER-Lite populated with this feature.
Please contact our Sales team (see
240H
Appendix A – Contacting Eurotech ,
page
241H
101 ) to discuss your requirements.
Jumper is fitted.
Jumper is not fitted.
3
2
1
Jumper fitted on pins 1-2.
3
2
1
Jumper fitted on pins 2-3.
VL
