93
ABOUT
RS-232C
ENGLISH
Connection
If the RS-232C cable is not connected correctly between this product and the PC, no
acknowledgement is transmitted.
Connect the RS-232C cable correctly, and fix it firmly with the connector set screws before
starting the operation.
For " ■■" in the data column, transmit the SPACE [20H] twice.
Function Command Parameter Data Contents
Image rotation RO 0 (0 °) ■■ To turn the image
1 (180 °)
Edge effect AP 0 (OFF) ■■ To set the edge enhancement
1 (Low)
2 (Mid)
3 (High)
White balance AW 0 (Manual) ■■ To switch the white balance mode
1 (Auto)
2 (One Push)
3 (R_Up)
4 (R_Down)
5 (B_Up)
6 (B_Down)
Text CT 0 (GRAPHICS) ■■ To set the contrast
1 (TEXT1)
2 (TEXT2)
3 (TEXT3)
Posi/Nega NP 0 (Posi) ■■ To set the Posi/Nega
1 (Nega)
Color/B&W CB 0 (Color) ■■ To set the Color/B&W
1 (B&W)
Local lockout LL 0 (OFF) ■■ To invalidate the operation of the front operating
1 (ON) panel and wireless remote control
Default DF 0 ■■ To reset to the default settings
Status request QS 0 ■■ To inquire about the unit state
2
ROM version QR 0 ■■ To inquire about the ROM version
1
2
3
4
ACK check SA 0 (OFF) ■■ To switch the ACK check mode
1 (ON)
CR addition SC 0 (OFF) ■■ To switch the CR addition settings
1 (ON)
