STORING
ENGLISH
3
STORING
Storing
G
M
Locked
Unlocked
(1)
Return the lamp to the original position. Then,
hold the setup grip of the camera column and fold
the camera column. At this time, the camera head
slides down and the lamp column also folds.
(2)
Lock the camera column and the lamp column by
turning the security lock.
Do not force down the camera column
and the lamp column when folding them.
Do not fold the camera column when the
close-up lens holder remains open, or the
close-up lens could be damaged.
Close-up
lens holder
