Preset Signals
This unit can display the video signals shown in the table below.
Corresponding signal Resolution (Dot)
Scanning frequency
Dot clock
frequency (MHz)
Format * 3 Horizontal
(kHz)
Vertical (Hz)
NTSC/NTSC4.43/
PAL-M/PAL60
720 x 480i 15.73 59.94 V
PAL/PAL-N/SECAM 720 x 576i 15.63 50.00 V
480/60i 720 x 480 15.73 59.94 13.50 R/Y
576/50i 720 x 576i 15.63 50.00 13.50 R/Y
480/60i 720 (1 440) x 480i * 2 15.73 59.94 27.00 D/H/DL
576/50i 720 (1 440) x 576i * 2 15.63 50.00 27.00 D/H/DL
480/60p 720 x 483 31.47 59.94 27.00 R/Y/D/H/DL
576/50p 720 x 576 31.25 50.00 27.00 R/Y/D/H/DL
720/60p 1 280 x 720 45.00 60.00 74.25 R/Y/D/H/DL
720/50p 1 280 x 720 37.50 50.00 74.25 R/Y/D/H/DL
1080/60i * 1 1 920 x 1 080i 33.75 60.00 74.25 R/Y/D/H/DL
1080/50i 1 920 x 1 080i 28.13 50.00 74.25 R/Y/D/H/DL
1080/24p 1 920 x 1 080 27.00 24.00 74.25 R/Y/D/H/DL
1080/24PsF 1 920 x 1 080i 27.00 48.00 74.25 R/Y
1080/25p 1 920 x 1 080 28.13 25.00 74.25 R/Y/D/H/DL
1080/30p 1 920 x 1 080 33.75 30.00 74.25 R/Y/D/H/DL
1080/60p 1 920 x 1 080 67.50 60.00 148.50 R/Y/D/H/DL
1080/50p 1 920 x 1 080 56.25 50.00 148.50 R/Y/D/H/DL
640 x 400/70 640 x 400 31.47 70.09 25.18 R/Y/D/H/DL
640 x 400/85 640 x 400 37.86 85.08 31.50 R/Y/D/H/DL
640 x 480/60 640 x 480 31.47 59.94 25.18 R/Y/D/H/DL
640 x 480/67 640 x 480 35.00 66.67 30.24 R/Y/D/H/DL
640 x 480/73 640 x 480 37.86 72.81 31.50 R/Y/D/H/DL
640 x 480/75 640 x 480 37.50 75.00 31.50 R/Y/D/H/DL
640 x 480/85 640 x 480 43.27 85.01 36.00 R/Y/D/H/DL
800 x 600/56 800 x 600 35.16 56.25 36.00 R/Y/D/H/DL
800 x 600/60 800 x 600 37.88 60.32 40.00 R/Y/D/H/DL
800 x 600/72 800 x 600 48.08 72.19 50.00 R/Y/D/H/DL
800 x 600/75 800 x 600 46.88 75.00 49.50 R/Y/D/H/DL
800 x 600/85 800 x 600 53.67 85.06 56.25 R/Y/D/H/DL
832 x 624/75 832 x 624 49.72 74.55 57.28 R/Y/D/H/DL
852 x 480/60 852 x 480 31.47 59.94 34.24 D/H/DL
1024 x 768/50 1 024 x 768 39.55 50.00 51.89 D/H/DL
1024 x 768/60 1 024 x 768 48.36 60.00 65.00 R/Y/D/H/DL
1024 x 768/70 1 024 x 768 56.48 70.07 75.00 R/Y/D/H/DL
1024 x 768/75 1 024 x 768 60.02 75.03 78.75 R/Y/D/H/DL
1024 x 768/82 1 024 x 768 65.55 81.63 86.00 R/Y/D/H/DL
1024 x 768/85 1 024 x 768 68.68 85.00 94.50 R/Y/D/H/DL
1066 x 600/60 1 066 x 600 37.64 59.94 53.00 D/H/DL
1152 x 864/60 1 152 x 864 53.70 60.00 81.62 D/H/DL
1152 x 864/70 1 152 x 864 63.99 70.02 94.20 R/Y/D/H/DL
1152 x 864/75 1 152 x 864 67.50 75.00 108.00 R/Y/D/H/DL
1152 x 864/85 1 152 x 864 77.09 85.00 119.65 R/Y/D/H/DL
1152 x 870/75 1 152 x 870 68.68 75.06 100.00 R/Y/D/H/DL
1280 x 720/60 1 280 x 720 44.76 60.00 74.48 R/Y/D/H/DL
1280 x 768/50 1 280 x 768 39.55 49.94 65.18 R/Y/D/H/DL
1280 x 768/60 1 280 x 768 47.70 60.00 80.14 R/Y/D/H/DL
1280 x 768/60 1 280 x 768 47.78 59.87 79.50 R/Y/D/H/DL
1280 x 800/50 1 280 x 800 41.20 50.00 68.56 R/Y/D/H/DL
1280 x 800/60 1 280 x 800 49.31 59.91 71.00 R/Y/D/H/DL
1280 x 800/60 1 280 x 800 49.70 59.81 83.50 R/Y/D/H/DL
1280 x 960/60 1 280 x 960 60.00 60.00 108.00 R/Y/D/H/DL
1280 x 960/85 1 280 x 960 85.94 85.00 148.50 R/Y
1280 x 1024/60 1 280 x 1 024 63.98 60.02 108.00 R/Y/D/H/DL
1280 x 1024/75 1 280 x 1 024 79.98 75.02 135.00 R/Y/D/H/DL
1280 x 1024/85 1 280 x 1 024 91.15 85.02 157.50 R/Y/D/H/DL
1360 x 768/60 1 360 x 768 47.71 60.02 85.50 D/H/DL
1360 x 768/60 1 360 x 768 47.70 60.00 84.72 D/H/DL
1360 x 768/60 1 360 x 768 47.72 59.80 84.75 D/H/DL
