en | Audio Cables (AUTODOME Cameras ONLY, except VG5-600 Models)
Power Supply Units (AUTODOME7000, MIC7000
cameras)
2020-10 | |
Installation Manual
Bosch Security Systems, Inc.
3
Earth Ground
9
Audio Input
4
RxD (not used)
5
TxD (not used)
6
Signal Ground (not used)
Notice!
Refer to the Installation Manual of your camera for configuring and using audio over an IP
Ethernet network.
