RGB 400 Series Specifications RGB 400 Series Specifications
Specifications, cont’d
Enclosure dimensions (RGB 402 and RGB 404)
Plate .................................... 4.50” H x 6.40” W
(11.43 cm H x 16.26 cm W)
Box ...................................... 3.75" H x 5.3" W x 2.5" D
(9.5 cm H x 14.2 cm W x 6.35 cm D) 3-gang
Interface ............................. 2.8" H x 5.3" W x 2.5” D
(7.1 cm H x 13.5 cm W x 6.4 cm D) (depth
is given with an HR cable attached)
Enclosure dimensions (RGB 408)
Plate .................................... 4.50” H x 8.33” W
(11.43 cm H x 21.15 cm W)
Box ...................................... 3.75" H x 7.38" W x 2.50" D
(9.50 cm H x 18.73 cm W x 6.35 cm D)
4-gang
Interface ............................. 2.8" H x 3.5" W x 2.5” D
(7.1 cm H x 8.9 cm W x 6.4 cm D)
(depth is given for the circuit board with
an HR cable attached)
Shipping weight (all models) .... 3 lbs (1.4 kg)
Vibration ....................................... NSTA 1A in carton
(National Safe Transit Association)
Approvals ..................................... UL, CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 2 years parts and labor
Specifications are subject to change without notice.
A-5
Audio output — RGB 404 (channels 1 and 2)
Number/type .............................. 2 buffered, stereo (2 channel),
balanced/unbalanced
Connectors .................................... 3.5 mm captive screw terminal,
5 conductor
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ..................................... ±0.1dB channel to channel
Drive (600 ohm) ........................... +14dBu, balanced at stated %THD+N
Audio output — RGB 406 and RGB 408
Number/type .............................. 1 buffered, stereo (2 channel),
balanced/unbalanced
Connectors .................................... 3.5 mm captive screw terminal,
5 conductor
Impedance .................................... 50 ohms, unbalanced, 100 ohms balanced
Gain error ..................................... ±0.1dB channel to channel
Drive (600 ohm) ........................... +14dBu, balanced at stated %THD+N
General
Power ............................................ 12 to 24VAC or VDC, 0.25 A, 5 Watts,
external (Order the power supply
separately.)
Temperature/humidity ............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non condensing
Rack mount .................................. No, but wall or furniture mountable
Enclosure type ............................. Metal
Enclosure dimensions (RGB 400 and RGB 406)
Plate .................................... 4.50” H x 4.60” W (11.43 cm H x 11.68 cm W)
Box ...................................... 3.75" H x 3.75" W x 2.5" D
(9.5 cm H x 9.5 cm W x 6.35 cm D) 2-gang
Interface ............................. 2.8" H x 3.5" W x 2.5” D
(7.1 cm H x 8.9 cm W x 6.4 cm D)
(depth is given for the circuit board with
an HR cable attached)
A-4
