RGB 400 Series Specifications RGB 400 Series Specifications
Specifications, cont’d
A-3
Audio input — RGB 402
Number/type .............................. 1 stereo, unbalanced (pass-through)
Connectors .................................... 2 RCA female jacks
Audio input — RGB 404
Number/type .............................. 2 stereo, unbalanced; 1.0Vrms (+4dBu),
20 Hz to 20 kHz
Connectors ..................................... Ch. 1 ........... 2 RCA female jacks
Ch. 2 ........... 3.5 mm stereo female jack
(2 channel), unbalanced;
tip (L), ring (R),
sleeve (ground)
Impedance .................................... 10 kohms, DC coupled
Minimum level ............................ 100mV
Maximum level ............................ +8.5dBu
Audio input — RGB 406 and RGB 408
Number/type .............................. 1 stereo, unbalanced; 1.0Vrms (+4dBu),
20 Hz to 20 kHz
Connectors .................................... 3.5 mm stereo female jack (2 channel),
unbalanced;
tip (L), ring (R), sleeve (ground)
Impedance .................................... 10 kohms, DC coupled
Minimum level ............................ 100mV
Maximum level ............................ +8.5dBu
Audio throughput — RGB 404 (channels 1 and 2),
RGB 406 and RGB 408
Gain ............................................... Unbalanced 0dB, balanced +6dB
Response ....................................... ±0.5dB @ 20 Hz to 20 kHz
THD + Noise ................................ 0.03% @1 kHz, 0.3% @ 20 kHz at rated
maximum output drive
S/N ................................................ >90dB, output 14dBu, balanced
Stereo channel separation .......... >95dB @ 1 kHz to 20 kHz
Audio output — RGB 402
Number/type .............................. 1 stereo, unbalanced
Connectors .................................... 1 pair solder cups
Specifications
A-2
These specifications apply to all models unless otherwise noted.
Video input
Number/type .............................. 1 analog RGBHV, RGBS, RGsB
Connectors .................................... 1 9-pin male D connector for MBC/LBC
cable or buffer
Nominal level(s) .......................... Analog — 0.3V to 1.45V p-p
Impedance .................................... 75 ohms or HI Z, switchable (set to
75 ohms if no local monitor is connected)
Horizontal frequency ................. 15 kHz to 150 kHz (optimum 15 kHz to 62
kHz)
Vertical frequency ....................... 30 Hz to 170 Hz
Return loss .................................... -30dB @ 5 MHz
Video throughput
Gain ............................................... Unity (0.7V), 15% with 3dB peaking
(0.8V), 30% with 6dB peaking (0.9V)
Bandwidth .................................... 300 MHz (-3dB)
Video output
Number/type/format ................ 1 analog RGBHV, RGBS, RGsB
Connectors .................................... 6 BNC female
Nominal level .............................. Analog 0.7V p-p, 0.8V p-p, or 0.9V p-p
(internal jumper-selectable) w/peaking
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
Sync
Input type ..................................... Autodetect RGBHV, RGBS, RGsB
(accepts RGsB but does not strip from
video)
Output type .................................. RGBHV at all times
RGBS at all times
RGsB only when input is RGsB
Input level .................................... 2.0V to 5.5V p-p with +0.2VDC offset
max.
Output level ................................. 4.0V to 5.0V p-p
Input impedance ......................... 10 kohms
Output impedance ...................... 75 ohms
Max propagation delay .............. 50 nS
Max rise/fall time ....................... 2.5 nS
Polarity .......................................... Positive or negative
