captured data fills the buffering capacity, old data is overwritten sequentially. When you press the MOVIE button, the
camera starts to record a movie of the set duration calculated retroactively from that point on the memory card.
With [End Trigger], a movie of the maximum possible duration is recorded. With [End Trigger Half], a movie of half
the maximum possible duration is recorded. With [End Trigger Half], the time it takes to record to the memory card is
also shorter than with [End Trigger].
End Trigger
End Trigger Half
(A): The point when the MOVIE button is pressed
(B): Recorded section
(C): Recording to memory card in progress (You cannot start the next session of shooting.)
(D): Buffering in progress
To redo shooting
You can cancel recording by selecting [Cancel] on the screen. However, the movie recorded up to the point you
cancelled will be saved.
Playback speed
The playback speed will vary as below depending on the assigned [ Frame Rate] and [ Record Setting].
[ Priority Setting] and shooting duration
Frame
Rate
Record Setting: 24p
50M*
Record Setting: 30p
50M/25p 50M
Record Setting: 60p
50M/50p 50M
240fps/250fps 10 times slower 8 times slower/10 times slower 4 times slower/5 times slower
480fps/500fps 20 times slower 16 times slower/20 times slower 8 times slower/10 times slower
960fps/1000fps 40 times slower 32 times slower/40 times slower 16 times slower/20 times slower
Only when [NTSC/PAL Selector] is set to NTSC. *
Priority
Setting
Frame
Rate
Effective pixel number read out from image
sensor
Shooting
duration
Quality Priority 240fps/250fps 1824×1026 Approx. 2 seconds
Quality Priority 480fps/500fps 1824×616 Approx. 1 seconds
Quality Priority 960fps/1000fps 1244×420 Approx. 1 seconds
