365
❚❚ AF-S DX NIKKOR 18–200mm f/3.5–5.6G ED VR II
A
Zoom Lock Switch
To lock the zoom ring, rotate it to the 18 mm position and slide the
zoom lock switch to LOCK. This prevents the lens extending under its
own weight while the camera is being carried from place to place.
D
Focus Distance Indicator
Note that the focus distance indicator is intended only as a guide and
may not accurately show the distance to the subject and may, due to
depth of field or other factors, not show ∞ when the camera is focused
on a distant object.
LOCK 18
Focal length mark Focus distance mark
Vibration reduction
ON/OFF switch (
0 367)
Lens mounting mark
(
0 23)
Rear lens cap
Lens cap
Zoom ring ( 0 33)
CPU contacts ( 0 307)
Focus ring ( 0 97)
Focus mode switch ( 0 97)
Vibration reduction mode
switch (
0 368)
Zoom lock switch
Focal length
scale
Focus distance indicator
