MVI56-S3964RT ♦ TControlLogix PlatformT Reference
TSiemens 3964R ProtocolT
Page 66 of 78 ProSoft Technology, Inc.
Value Description
16 Port 1 STX Not Received
17 Port 2 Requests
18 Port 2 Responses
19 Port 2 Errors Sent
20 Port 2 Errors Received
21 Port 2 DLE Not Received
22 Port 2 STX Not Received
23 Backplane Writes
24 Backplane Reads
25 Backplane blocks parsed
26 Backplane Errors
27 Port 1 Current Error
28 Port 1 Last Error
29 Port 2 Current Error
30 Port 2 Last Error
5.6 Error Codes
Error Code Description
-2 0xFFFE DLE could not be sent
-10 0xFFF6 DLE not received in time
-11 0xFFF5 Communication Timeout occurred
-20 0xFFEC Invalid character or acknowledge received
-30 0xFFE2 Amount of user data is 0 or greater than 256 words
-31 0xFFE1 Reject pending job from the processor due to low priority
-32 0xFFE0 No reaction (STX) from Communication Partner
-33 0xFFDF Communication Partner error occurred
-34 0xFFDE Job code not defined
-35 0xFFDD High/High (priority) initialization conflict occurred
-36 0xFFDC First Header Byte does not match telegram type
-37 0xFFDB Character received was not an STX
-38 0xFFDA S3964R problem occurred after connection to Communication Partner was
established
-39 0xFFD9 S3964R communication could not be established/finished
