Feature Specification
Model IKVM-16010
Host Port Connector VGA
Host Ports 16
Console Type USB or PS/2
Max. Distance (KVM switch --
Host)
16 feet (5m)
Video Resolution(Local
Console)
1920 x 1440
Video Resolution(Remote
Console)
1680 x 1050 for CAT5-Based 500 feet remote console
1280 x 1024 for CAT5-Based 1000 feet remote console
1600 x 1200 for IP-Based remote console
Console Ports 1 Local console, plus
1 Optional Modules: CAT5-Based or IP-Based Remote Console
Flash Port DC2.5F
CAT5-Based Remote Module RJ-45 Connector
CAT5 console up to 1000 feet away from KVM switch with superior
auto-adjust RGB signals capability
IP-Based Remote
Module
RJ-45 8P8C for 10/100M Ethernet
DB-9 male for Configuration console, Modem, Null modem, and serial
power control
Mini USB 2.0 receptacle
Daisy Chain Support Daisy Chaining with both Bus (8-layer) and Tree (2-layer)
topologies
Connector DB15 (Female Type)
Computers Selection On Screen Display (OSD) Menu, Hot Key, Push Button
Hotkey Provide various Hotkey (Scroll-Lock/ Caps-Lock/ Num-Lock/ Alt/ Ctrl/ Win)
Computer Port LED’s 2 LED’s per Host port: ON LINE (Red), SELECT (Green)
7-seg LED 1 set for Bank display
Security Provide ACL (Access Control List) security function, store up to 8
independent ACL’s of controllable computer lists
Multilingual OSD (On Screen
Display) control
8 languages (English, France, Germen, Spanish, Italian, Russian,
Japanese, Simplified Chinese)
Auto-Scan Intervals 5 ~ 99 Sec.
Keyboard Emulation PS/2 or USB
Mouse Emulation PS/2 or USB
Max. Connected Computers Up to 8192
Housing Metal
Power DC Power adapter : 12V, 1A
Operation Temperature 0 ~ 50℃
Storage Temperature -20 ~ 60℃
Humidity 0~80%, Non-Condensing
Mechanical 19” Rackmount, 1U
Dimension (mm) 444.5 * 160 * 44.3
