User’s Manual of GS-4210-8P2T2S
The page includes the following fields:
Object Description
 Port The switch port number of the logical port
 Coordinate Display the current coordinate
 Civic Address Display the current civic address
 ESC ELIN Display the current ESC ELIN
4.12.8 LLDP Overloading
The LLDP Port Overloading screen in Figure 4-12-16 appears.
Figure 4-12-16 LLDP Port Overloading Table Page Screenshot
The page includes the following fields:
Object Description
 Interface The switch port number of the logical port
 Toltal (Bytes) Total number of bytes of LLDP information that is normally sent in a packet
 Left to Send (Bytes) Total number of available bytes that can also send LLDP information in a packet
292
