User’s Manual of GS-4210-8P2T2S
Figure 4-9-55 DAI Port Setting Page Screenshot
The page includes the following fields:
Object Description
 Port The switch port number of the logical port
 Type Display the current port type
 Src-Mac Chk Display the current Src-Mac Chk status
 Dst-Mac Chk Display the current Dst-Mac Chk status
 IP Chk Display the current IP Chk status
 IP Allow Zero Display the current IP allow zero status
4.9.8.4 Statistics
Configures switch ports as DAI trusted or untrusted and check mode. DAI Port Setting screen in Figure 4-9-56 appears.
Figure 4-9-56 DAI Port Setting Page Screenshot
240
