Page 162
User’s Manual of GS-4210-8P2T2S
Static:
Interface is a member of the IGMP.
Buttons
: Click to apply changes.
4.7.3 IGMP Snooping Statics
This page provides IGMP Snooping Statics. The IGMP Snooping Statics screen in
Figure 4-7-20
appears.
Figure 4-7-20 Forward All Setting Page Screenshot
The page includes the following fields:
Object
Description
Total RX
Display current total RX
Valid RX
Display current valid RX
Invalid RX
Display current invalid RX
Other RX
Display current other RX
Leave RX
Display current leave RX
Report RX
Display current report RX
General Query RX
Display current general query RX
Special Group Query
RX
Display current special group query RX
162
