Connectors, Jumpers and LEDs
2-10 eXtremeRAID 3000 Installation Guide
3. Remove the eXtremeRAID 3000 controller from the anti-static bag as
shown in Figure 2-6. Always handle the controller by the edges and
wear a ground wrist strap.
Figure 2-6. Remove the controller from the Anti-static Bag
4. Plug (install) the controller firmly into the any 32 bit or 64 bit PCI slot
and wear a ground wrist strap as shown in Figure 2-7. Notice that the
black handle must fit into the side slot for a proper fit.
Figure 2-7. Plug the Controller into any 32 bit or 64 bit PCI Slot
Ground
Wrist Strap
Black Handle
