Connectors, Jumpers and LEDs

2-8

eXtremeRAID 3000 Installation Guide

Figure 2-3. eXtremeRAID 3000 Controller with LEDs (back side)

3- Fibre Activity

1- SCSI Activity

2- Single Ended Mode

4- LVD Mode

5- Host Activity 6- Cache Activity

7- Diagnostic

LED

8- Fibre Ch 1

Activity
