96
DBP - Rev 6/93
9. Tables and Summaries
9.1 Display diagnostics
Each amplifier's fault is stored immediately in the DCB RAM. In addition to
that, a Failure Message is displayed. Following are all the valid Display
Messages:
Event Display Display
after
Recurring
DIP switch 1 - ON BAUD OK
Load is under cont. current limit CLIM C-OK
Battery Low BATT B-OK
Abort condition (hardware only) ABRT A-OK
Amplifier's power stage disabled * AMPD H-OK
-15V out of limits -15V F-OK
Under or Over Voltage VOLT F-OK
+15V out of limits +15V F-OK
Over Temperature TEMP F-OK
Commutation problem (for brushless drives
only)
CMMT F-OK
Short condition at the power outputs SHRT F-OK
* The AMPD message appears in two cases:
1. When MO (Motor Off) command is given.
2. Position error exceeds the allowed value.
