Section 9 TROUBLESHOOTING
9-12
• Misfeed in the optional Side Feeder
If the message below is displayed, a misfeed has occurred in the
optional Side Feeder. Perform the following procedure to remove the
jammed paper.
Inch specification
Paper misfeed.
1.Remove paper from between Copier and
Side Paper Deck.
2.Reset Side Paper Deck to Mainframe.
JAM 00
Metric specification
Paper misfeed.
1.Remove paper from between copier and
side feeder.
2.Reset side feeder to mainframe.
JAM 00
1 Disconnect the Side Feeder from the main body of the
copier.
2 If there is any jammed paper inside the coupling area
between the Side Feeder and the copier, remove it.
3 Reconnect the Side Feeder to the copier.
If there is any jammed paper inside the Side Feeder, go to
the next step.
4 Open the upper cover to the Side Feeder.
5 Remove the jammed paper.
6 Close the upper cover to the Side Feeder.
