Rosen Aviation RosenView VX Technical Manual
Document Number: 100640 Revision: G
Date: 9/19/12
Template: 4.4.1.6FM1; Revision A; 31 May, 2012 Page 21 of 23
5.3. Specifications
Table 12 RosenView VX specifications
Mechanical packaging:
Weight 3.5 lbs
Power Requirements 28VDC
Audio/Video Outputs:
DVD Video Out
DVD Audio Out
Auxiliary Video In
Auxiliary Audio Line In
Switched Video Out
Switched Audio Out
1Vpp, 75 ohms
1V RMS (0db FS), 600 ohms
1Vpp, 75 ohms
1V RMS nominal, 4.7k ohms; Max Input Voltage
5.8Vpp
1Vpp, 75 ohms; unity gain from auxiliary video
input
Unity gain from auxiliary audio input is 600 ohms
Operating Temperature 0ºC - 50ºC
Warranty 2 year
5.4. Technical Support
If you need assistance in configuring a RosenView VX, please contact Rosen Aviation at
541.342.3802 or 888.668.4955.
6. DEFINITIONS
ARINC Aeronautical Radio, Incorporated. Data bus standard for transmission of
avionics data on a differential serial bus
ARNAV Alternate format for GPS data, where each ASCII sentence is preceded with
a hex value of 0x02
ASCII American Standard Code for Information Interchange
AUX Auxiliary
CVBS Composite Video Base-band Signal
DC Direct Current – voltage from an aircraft battery or generator
ESD Electrostatic Discharge
FMS Flight Management System
GND Ground
GMT Greenwich Mean Time
GPS Global Positioning System
HD High density (e.g., connector description)
